Description

20101605 * Screw M6*80 for 0.75Kw drive motor

20101606 Screw M6*90 for 1.0Kw drive motor

31101003 * Motor assy. 0.75Kw for EPT15H

31101156 * Motor assy. with spline sleeve 0.75Kw for EPT15H

31501005 * Motor assy. 1.0Kw for EPT20H

31101157 * Motor assy. with spline sleeve 1.0Kw for EPT20H

31102013 * Axle

31102129 * Drive wheel Ø140*55mm with REACH certified

31101077 * Gearbox assy.(No motor, drive wheel, axle, etc)

31101138 * Driving unit assy. (0.75Kw Motor) for EPT15H

31501022 * Driving unit assy. (1.0Kw Motor) for EPT20H

31101002 * Brake assy.

31101084 * Brake assy

20105001 * Screw M4*10

31102131 * Brake pad

31102142 * Spline sleeve for old brake

21601003 * Flat key

20801009 * Circlip

31102163 * Spline sleeve for new brake

20501012 * Bearing 6006-2Z

20501011 * Bearing 6205-2Z

21104003 * Oil seal

31101137 * Gears assy.

20902001 * Locating pin

21104002 * Framework oil seal

31101082 * Gearbox cover assy.

20101501 * Screw

20401004 * Nut

31102007 * Nut cap

20303003 * Screw M4*10

30202024 * Fixed shaft of piston rod

31501014 * Cylinder assy. Ø35

20101801 * Screw M8*20

20601001 * Washer Ø8

30202035 * Clip

20202601 * Screw M6*12 (2020.11.5~) updated

30202022 * Oil pipe connector

31101076 * Hydraulic unit assy.

31101046 * Hydraulic unit assy

30202054 * Plug Screw

30202021 * Oil pipe

31102015 * Mounting plate

20103602 * Screw M6*16

20304503 * Screw M6*16

31402005 * Cable sleeve

30202036 * Oil tank block

10301014 * Lifting limitation inching switch

20202301 * Screw M3*16

20202604 * Screw M6*18

31102117 * Mounting plate for guide cable

31101126 * Hydraulic unit assy. with mounting plate & oil pipe(Inc.7~13,15~18 )

31101132 * Hydraulic unit assy. with mounting plate & oil pipe(Inc.7~13,15~18)

31102173 * Rubber sleeve

31101070 * Hydraulic motor

31102074 * Oil strainer

31102075 * Hydraulic pump

31102077 * O-ring Ø90*2.65

31102164 * Solenoid valve

31102081 * Pressure relief valve

31102082 * Relief value

31102162 * Coil

31102073 * Coupling

31102078 * Lower cover of oil box

31102187 * Carbon brush

31102093 * Hydraulic motor

31102097 * Hydraulic pump

21101013 * O-ring Ø90*2.65

31102100 * Oil strainer

31102102 * Balance valve

31102103 * Solenoid valve

31102104 * Coil

31102108 * Relief value assy.

31102098 * Lower cover of oil box

31102188 * Carbon brush

31102110 * Poston rod

31102113 * Guide sleeve

31102184 * Guide sleeve

20101608 * Screw

21103005 * Washer

31101086 * Pump seal kits (Inc. item 1/2/3/4/6/7/9)

31101036 / Frame 550*1150

31101041 / Frame 685*1150

31101042 / Frame 685*1220

31101019 / Frame 520*1150

31101038 / Frame 550*800

31101065 / Frame 550*1000

31101069 / Frame 550*1500

31101072 / Frame 685*800

31101075 / Frame 685*1000

31101128 / Frame 685*1300

31101044 / Frame 685*1500

31101091 / Frame 550*700

31101104 / Frame 550*750

31101073 / Frame 550*900

31101116 / Frame 550*950

31101040 / Frame 550*1070

31101039 / Frame 550*1120

31101037 / Frame 550*1220

31101047 / Frame 685*900

31101045 / Frame 685*1070

31101043 / Frame 685*1120

31101097 / Frame 685*1400

31101106 / Frame 520*800

31101107 / Frame 520*900

31101112 / Frame 520*1000

31101020 / Frame 520*1070

31101096 / Frame 520*1220

31101098 / Frame 520*1300

20304502 * Screw M5*16

31102041 * Cover plate (~2022.9.15)

31102183 * Cover plate (2022.9.15~)

10301092 * Li-Battery 48V/10Ah

10301091 * Li-Battery 48V/15Ah

30102022 * Cushion block (~2022.05.31)

10601007 * Cushion block (2022.06.01~)

10301002 * Emergency Stop Switch

30102021 * Long Shaft (550)

30102031 * Long Shaft (685)

21401001 * Self-Lubricating Bearing 30*25*30

31501001 * Rocker Arm (550)

31501003 * Rocker Arm (685)

20802002 * Gasket Ø25

21401002 * Self-Lubricating Bearing 16*18*15

30102024 * Shaft

20801001 * Gasket Ø16

30102059 * Joint

20403001 * Nut M22*1.5

30101014 * Connecting Rod (1150)

30101015 * Connecting Rod (1220)

30101063 / Connecting Rod (800)

30101061 / Connecting Rod (1000)

30101069 / Connecting Rod (1300)

30101058 / Connecting Rod (1500)

30101064 / Connecting Rod (600)

30101068 / Connecting Rod (700)

30101071 / Connecting Rod (750)

30101034 / Connecting Rod (870)

30101065 / Connecting Rod (900)

30101072 / Connecting Rod (950)

30101033 / Connecting Rod (1070)

30101050 / Connecting Rod (1120)

30101070 / Connecting Rod (1400)
