| Product Name | Emergency stop switch |
| PN | 1070334008 |
| Model | S100/80 |
| maximum recommended contact voltage |
36V |
| current rating | 60A/80A |
| warranty | 1 years |
| Used for | Electric pallet truck electric stacker |
1 9000002189 Tiller block 1 Rubber
2 9000002175 Left drive button 1 ABS
3 9000008334 Accelerator 1 BD-190
9000012014 Accelerator 1 ET-191E
4 9000002177 Accelerator connector ABS BD-190
5 9000002188 Plastic cover 1 ABS
6 9000002176 Right drive button 1 ABS
7 0000023304 Screw 2
8 0000025003 Elastic washer
9 0000025026 Washer
10 0090000190 Screw
11 0090000189 Screw
12 9000002179 Lower cover 1 ABS
13 0000023138 Screw
14 0000023040 Screw
15 9000002178 Upper cover
16 9000002311 Micro switch plate 1 ABS
17 9000002161 Micro switch 4
18 0090000261 Screw
19 9000002310 Micro switch plate 2 ABS
20 0090000262 Tapping screw
21 9000002180 Belly button 1 ABS
22 9000002181 Belly block 1 ABS
9000009801 Indicator
9000002163 S100/80
1070334008 Emergency button
9000001977 Instrument panel
9000001975 Instrument plate
9000002065 Control board
108042000 1 Charger 24V/8A QQE192-8CH17-26B
1080420002 Charger 24V/8A QQE192-8CH18-26B
1010434009 Charger power cord
