Forklift parts 31401001 Handle tube assy’ for CBD15-WS electric pallet truck
| Product name | Handle tube assy' | |
| Part number | 31401001 | |
| Used for | CBD15-WS / CBD20-WS electric pallet truck | |
Description
| Product name | Handle tube assy’ | |
| Part number | 31401001 | |
| Used for | CBD15-WS / CBD20-WS electric pallet truck | |
| Relevant Parts | 31401001 | Handle tube assy. |
| 31101078 | Control box assy | |
| 31101196 | Control box assy. | |
| 31101079 | Handle assy. | |
| 31101197 | Handle assy. | |
| 21402003 | Self‑Lubricating Bearing | |
| 20901001 | Spring Pin Ø5*35 | |
| 31102127 | Handle shaft | |
| 10302018 | Handle cables | |
| 31102124 | Plastic cable clamp | |
| 31102038 | Pressure Roller with bearing | |
| 31102039 | Roller Axle | |
| 20901010 | Spring Pin 4*20 | |
| 30202004 | Emergency reverse button | |
| 30202005 | Spring | |
| 10301010 | Inching switch | |
| 30202002 | Bottom cover | |
| 20101402 | Screw M4*16 | |
| 20101401 | Screw | |
| 10301012 | Potentiometer | |
| 30202008 | Inner Column spacer | |
| 30202007 | Outer Column spacer | |
| 30202009 | Control Knob | |
| 30202057 | Control Knob | |
| 20302008 | Screw M3*12 | |
| 20301004 | Screw M3*16 | |
| 10301061 | Monitor (Intelligent control) option | |
| 30202003 | Front cover | |
| 30202006 | Sticky board | |
| 31101012 | Potentiometer assy. | |
| 31101134 | Potentiometer assy. | |
| 31101081 | Handle upper cover assy. | |
| 20101405 | Screw M4*12 | |
| 10302055 | Cable harness for control box assy. | |
