Description

1 5300500004 Handle assembly(手柄总成)

2 2000508001 Outer covering plate(手柄座盖板)

3 2000537002 Washer(垫圈)

4 2000541002 Screw(螺钉)

5 2000512002 Lubricated bush(自润滑轴承)

6 2000513001 Pin shaft(销轴)

7 2000536001 Spring pin(弹性销)

8 2000534003 Rubber washer(缓冲垫)

9 2000931004 Screw(螺钉)

10 2000534002 Rubber sleeve(轴套)

11 2000513003 Pin shaft(销轴)

12 2000541004 Screw(螺钉)

13 4300534001 Rubber sack(橡胶密封圈)

14 2000525004 Screw(螺钉)

15 2000535005 Installing plate(调整块)

16 2000504001 Steel ball(钢球)

17 2000507004 Inching switch(微动开关)

18 2000537003 Washer(垫圈)

19 2000541001 Screw(螺钉)

20 2000541003 Screw(螺钉)

21 2000537001 Washer(垫圈)

22 2000508002 Inner covering plate(盖板)

23 4000501002 Handle socket(手柄座)

24 4000517004 Cannula(手把连接套)

25 7300500001 Electron handgrip(电子转向)

26 5501221001 Gear(主动齿轮)

27 5500521001 Gear(被动齿轮)

28 9300200001 Sensor assembly(传感器总成)

29 5300500005 Handle assembly(手柄总成)

30 5300500004 Handle assembly (手柄总成)

31 5300500002 Switch box assembly (控制盒总成)

32 2000442001 Screw (螺钉)

33 4300501004 Handle tube (铝手把)

34 6000502002 Pneumatic spring seat (气弹簧座)

35 2000525012 Joint (气弹簧球头)

36 4000519004 Pneumatic spring complete (气弹簧)

37 2000527002 Snap ring (挡圈)

38 2000520003 Joint (下接头)

39 2000525006 Shaft (轴)

40 1000527001 Snap ring (挡圈)

41 4300501003 Covering plate (盖板)

42 2000542001 Screw (螺钉)

43 5300500002 Switch box assembly (控制盒总成)

44 5300518003 Emergency reverser button cover (紧急换向按钮盖)

45 2000519004 Spring (弹簧)

46 5300500001 Cover assembly (手柄盖总成)

47 4300500004 Stepped switch assembly (行走开关总成)

48 2000507002 Emergency reverser button (紧急换向按钮)

49 4300517001 Handle (手柄)

50 6000131007 Screw (螺钉)

51 1001437003 Washer (垫圈)

52 1200518001 Supporting plate (支撑板)

53 3201431001 Screw (螺钉)

54 6000131006 Screw (螺钉)

55 9300517001 Seat (微动开关座)

56 1000515002 Shell (接插件母胶壳)

57 1000515001 Shell (接插件公胶壳)

58 5300500005 Handle assembly (手柄总成)

59 4300500005 Switch box assembly (控制盒总成)

60 2000442001 Screw (螺钉)

61 4300501004 Handle tube (铝手把)

62 6000502002 Pneumatic spring seat (气弹簧座)

63 2000525012 Joint (气弹簧球头)

64 4600519002 Pneumatic spring complete (气弹簧)

65 2000527002 Snap ring (挡圈)

66 2000520003 Joint (下接头)

67 2000525006 Shaft (轴)

68 1000527001 Snap ring (挡圈)

69 4300501003 Covering plate (盖板)

70 2000542001 Screw (螺钉)

71 4300500005 Switch box assembly (控制盒总成)

72 4300508001 Emergency reverser button cover (紧急换向按钮盖)

73 2000519004 Spring (弹簧)

74 4300500007 Cover assembly (手柄盖总成)

75 4300500004 Stepped switch assembly (行走开关总成)

76 2000507002 Emergency reverser button (紧急换向按钮)

77 4300517001 Handle (手柄)

78 6000131007 Screw (螺钉)

79 1001437003 Washer (垫圈)

80 1200518001 Supporting plate (支撑板)

81 3201431001 Screw (螺钉)

82 6000131006 Screw (螺钉)

83 9300517001 Seat (微动开关座)

84 1000515002 Shell (接插件母胶壳)

85 1000515001 Shell (接插件公胶壳)

86 4300500004 Stepped switch assembly (行走开关总成)

87 2000538005 Screw (螺钉)

88 2000507003 Inching switch (微动开关)

89 2000535001 Isolate block (绝缘块)

90 2001141005 Screw (螺栓)

91 4300518003 Fastening bracket (固定支架)

92 1000504001 Washer (垫圈)

93 2000539002 Nut (螺母)

94 4300501005 Cam (凸轮)

95 4300513001 Cam Shaft (凸轮安装轴)

96 1002343003 Rack (齿条)

97 2000519004 Spring (弹簧)

98 4300900002 Screw (螺钉)

99 2001437005 Spring washer (垫圈)

100 4300540001 Right control knob (右控制手柄)

101 4300512001 Shaft sleeve (轴套)

102 4300535001 Fastening bracket (固定支架)

103 2000541004 Screw (螺钉)

104 4300540002 Left control knob (左控制手柄)

105 4300518004 Baffle (挡板)

106 2000521001 Gear (齿轮)

107 4700418001 Fastening bracket (固定支架)

108 4700400001 Potentiometer (电位器)

109 7800330001 Screw (螺钉)

110 7800311001 Washer (垫圈)

111 7800318001 Bracket (变速上浮动挡)

112 7800313001 Axostyle (滑动轴)

113 5800318001 Spring (弹簧)

114 7800300001 Electromotor (电动机)

115 1000131001 Screw (螺钉)

116 2001037001 Washer (垫圈)

117 9300400002 Encoder (编码器总成)

118 5501221004 Gear (齿轮)

119 7800337001 Washer (垫圈)

120 7800330002 Screw (螺钉)

121 7800318002 Bracket (浮动挡)

122 6000131005 Screw (螺钉)

123 300318001 Flange (浮动架)

124 300320001 Axletree (变速箱大轴承)

125 2000931008 Screw (螺钉)

126 2000100002 Gear box assembly (齿轮箱总成)

127 7800321001 Gear (齿轮)

128 4000332001 Drive wheel assembly (驱动轮总成)

129 2000325002 Nut (螺母)

130 9300312001 Quoit (垫圈)

131 8700406001 Limitation switch (光电开关)

132 9300312002 Sleeve (衬套)

133 1500300001 Motor (转向电机总成)

134 5800312002 Dust ring (防尘圈)

135 5800312001 Sleeve (防尘圈套)

136 5800335001 Detent ring (孔用挡圈)

137 7300342001 Screw (平端螺丝)

138 2000130002 Screw (螺栓)

139 7800321001 Gear (齿轮)

140 2000125001 Nut (螺母)

141 2000121006 Gear (齿轮)

142 2000120003 Bearing (轴承)

143 2000141001 Screw (螺栓)

144 2000625001 Bolt (六角头螺栓)

145 2000603010 Washer (垫圈)

146 2000111002 Sider cover (箱体侧盖)

147 2000128002 O-ring (0 型圈)

148 2000130001 Bolt (六角头螺栓)

149 2000135001 Washer (垫圈)

150 2000121002 Gear (齿轮)

151 2000120002 Bearing (轴承)

152 2000137001 Washer (垫圈)

153 2000137002 Washer (垫圈)

154 4000201001 Gear (齿轮)

155 4000101001 Flat (平键)

156 2001037001 Circlip (弹性挡圈)

157 2000731003 Screw (螺栓)

158 2000120001 Bearing (轴承)

159 2000105001 Seal washer (密封圈)

160 2000121003 Spline Shaft (花键轴)

161 2000126001 Gear box body (齿轮箱箱体)

162 2000130002 Screw (螺栓)

163 7800321001 Gear (齿轮)

164 2000125001 Nut (螺母)

165 2000121006 Gear (齿轮)

166 2000120003 Bearing (轴承)

167 2000141001 Screw (螺栓)

168 2000625001 Bolt (六角头螺栓)

169 2000603010 Washer (垫圈)

170 2000111002 Sider cover (箱体侧盖)

171 2000128002 O-ring (0 型圈)

172 4600113001 Nut (螺母)

173 2000121002 Gear (齿轮)

174 2000120002 Bearing (轴承)

175 2000137001 Washer (垫圈)

176 2000137002 Washer (垫圈)

177 4000201001 Gear (齿轮)

178 4000101001 Flat (平键)

179 2001037001 Circlip (弹性挡圈)

180 2000731003 Screw (螺栓)

181 2000120001 Bearing (轴承)

182 2000105001 Seal washer (密封圈)

183 4600113002 Spline Shaft (花键轴)

184 2000126001 Gear box body (齿轮箱箱体)

185 7800300003 Gear box assembly (变速箱总成)

186 301000001 Brake assembly (电磁制动器)

187 2001021001 Spline (花键轴套)

188 2001427001 Snap ring (轴用挡圈)

189 2001012001 Sleeve (定位套)

190 4600628001 O-ring (0 型圈)

191 4001404001 Flat key (平键)

192 301400001 Motor (电机)

193 301431001 Screw (螺栓)

194 301435001 Position sleeve (过渡定位套)

195 2001405001 Dust ring (骨架油封)

196 2001228001 O-ring (0 型圈)

197 2001420001 Bearing (轴承)

198 2001427001 Snap ring (轴用挡圈)

199 2001227003 Snap ring (轴用挡圈)

200 2000121005 Gear (齿轮)

201 2001435002 Semicircle key (半圆键)

202 2001425002 Nut (螺母)

203 4601402001 Joint (磁钢头)

204 301427001 Washer (垫圈)

205 2001441001 Screw (螺栓)

206 1801411001 Cover (刹车盘上盖)

207 1801411002 Wire saddle (线套)

208 7801006001 Circuit board (编码器线路板)

209 4600600001 Cylinder assembly (起升油缸)

210 2000742001 Screw (螺钉)

211 4600603001 Oil pipe (油管)

212 4300639001 Nut (螺母)

213 4300603014 Joint (接头)

214 1000628002 O-ring (O型圈)

215 4300603003 Soft oil pipe (软油管)

216 2000603016 Joint (接头)

217 2000603011 Washer (垫圈)

218 4000600007 Hydraulic power unit(old)(老款液压动力单元)

219 4600600001 Hydraulic power unit(new)(新款液压动力单元)

220 2500612001 Washer (垫片)

221 2500603017 Joint (接头)

222 4600605001 Dust ring (防尘圈)

223 2500605001 Seal washer (密封圈)

224 2000603011 Washer (垫圈)
