Description

| 1 | 02.01.2207 | Contactor | 1 |

| 2 | 03.1045 | Hoop | 1 |

| 3 | 02.DJ.33631 | Motor | 1 |

| 4 | 02.01.9367 | Coil | 1 |

| 5 | 02.01.9334 | Solenoid Valve | 1 |

| 6 | 19.1385 | Silencer | 1 |

| 7 | 02.01.90291 | Overflow Valve | 1 |

| 8 | 02.01.9332 | Coupler | 1 |

| 9 | 02.01.9353 | Center Block | 1 |

| 10 | 03.05162 | O-Ring | 1 |

| 11 | 02.01.9153 | Plug | 3 |

| 12 | 02.01.9028 | Check Valve | 1 |

| 13 | 02.01.9068 | G1/4 Pressure Filling Valve | 1 |

| 14 | 02.YYL.3980 | G1/4 Oil Return Pipe | 1 |

| 15 | 03.1062 | O-Ring | 1 |

| 16 | 02.01.9339 | Oil Tank | 1 |

| 17 | 02.YYL.3989 | Gear Pump | 1 |

| 18 | 03.0007 | 5 Spring Washer | 2 |

| 19 | 03.03646 | M5×60 Screw | 2 |

| 20 | 03.00491 | 4 Flat Washer | 4 |

| 21 | 03.0008 | 4 Spring Washer | 4 |

| 22 | 03.0123 | M4×10 Screw | 4 |

1 02.XDC.3415 20Ah Lithium Battery 1

1 02.XDC.3423 30Ah Lithium Battery 1

1 02.XDC.3416 40Ah Lithium Battery 1

1 02.XDC.3417 60Ah Lithium Battery 1

2 01 02.KZQ.2151 1212P Controller

2 02 02.KZQ.2167 1212P Controller

3 03.01410 M5×25 Screw 2

4 03.0007 5 Spring Washer 4

5 02.01.3057 Fuse Base 1

6 03.0055 5 Flat Washer 2

7 03.0133 M5×16 Screw 2

8 19.03450 Fuse 1

9 03.02151 M3×8 Screw 2

10 19.03620 Buzzer 1

11 02.CDQ.3408 Asia Charger 1

11 02.CDQ.3407 EU Charger 1

11 02.CDQ.3437 U.S Charger 1

11 02.CDQ.3438 U.K Charger 1

12 02.BMQ.2201 Under voltage alarm

1 20101030196 Handle Wire 手柄线束

2 20101030197 Frame Wire 车体线束

1 02.XSXC.PJ.0009 车体线束 Frame Wiring Harness

2 02.XSXC.PJ.0010 手柄线束 Handle Wiring Harness 1

3 02.XSXC.PJ.2004 车体电源线 Frame Power Wire 1

4 02.XSXC.PJ.2005 电机线 Motor Wire 1

5 02.XSXC.PJ.4001 熔断器-控制器 Fuse-Controller 1

1 02.XDC.3379 锂电池 20Ah Lithium Battery 1

1 02.XDC.2330 锂电池 35Ah Lithium Battery 1

2 02.CDQ.3376 亚标充电器 Asia Charger 1

2 02.CDQ.3377 欧标充电器 EU Charger 1

2 02.CDQ.3378 英标充电器 U.K Charger 1

2 02.CDQ.3379 美标充电器 U.S Charger 1

3 03.0127 螺钉 M4×6 Screw 4

4 03.0008 弹垫Φ4 Spring Washer 4

5 40.14.064 弹簧片 Leaf Spring 2

6 19.03620 蜂鸣器 Buzzer 1

7 03.02151 螺钉 M3×8 Screw 2

8 01 02.KZQ.2151 控制器 1212P Controller 1 -210522

02 02.KZQ.2167 控制器 1212P Controller 1 210522-

8 02.KZQ.2376 控制器 D2 Controller 1

9 03.01410 螺钉 M5×25 Screw 2

10 03.0007 弹垫Φ5 Spring Washer 4

11 02.01.3057 熔断器座 Fuse Base 1

12 03.0133 螺钉 M5×16 Screw 2

13 03.0055 平垫Φ5 Flat Washer 2

14 19.03450 保险丝 fuse 1

1 ME2T-685-35-0001 柱塞杆 Plunger Lever 1

2 DHS32 防尘圈 Dust Ring 1

3 GB/T3452.1-1992 0 型圈 O-Ring 1

4 UHS32 密封圈 Seal Ring 1

5 MA2T-685-0050 密封垫Φ10 Gasket 3

6 C-10 螺塞 Plug Screw 3

7 ME2T-685-35-0002 外缸 Outer Cylinder 1

8 GB/T3452.1-1992 0 型圈 O-Ring 1

9 GB/T3452.1-1992 0 型圈 O-Ring 2

10 MA2T-685-35-0003 内缸 Inner Cylinder 1

11 ME2T-685-0020 泵芯 Pump Core 1

12 C-13 弹簧盖 Gland 1

13 ME2T-685-0030 弹簧 Spring 1

14 DHS18 防尘圈 Dust Ring 1

15 MA2T-685-0180 钢球 Steel Ball 1

16 C-8 安全阀座 Safety Seat 1

17 C-17 安全阀弹簧 Relief Valve Spring 1

18 C-9 安全阀调节螺钉Safety valve adjusting screw 1

19 ME2T-685-0040 开关板 Switch Plate 1

20 圆柱销Φ8×50 Round Pin 1

21 GB/T73-1985 螺钉 M6×25 Screw 1

22 GB/T41-2000 螺母 M6 Nut 1

23 C-11 铜螺母 Cooper Nut 1

24 CDB-MA2T-685-0240 密封垫Φ20 Gasket 2

25 GB/T3452.1-1992 0 型圈 O-Ring 2

26 ME2T-685-0040 顶杆 Mandrel 1

27 C-15 顶杆弹簧 Ejector Spring 1

4.2 手动油缸 Hand Cylinder

28 MA2T-685-0270 钢球 Steel Ball 1

29 堵头 Plug 2

30 GB/T3452.1-1992 0 型圈 O-Ring 2

31 ME2T-685-35-0060 油泵焊接 Oil Pump Welding 1

32 MA2T-685-35-0170 定位杆 Positioning Rod 1

33 H-3290 阀体 Valve Body 1

34 H-3310 阀芯 Spool 1

35 H-3320 阀芯弹簧 Spool Spring 1

36 C-7 螺塞 Plug Screw 1

1 16.0038 肚皮开关 Belly Switch 1

2 16.0246 按钮开关 Button Switch 2

3 02.DLB.317703 电量表 Electricity Meter 1

4 02.FGJ.32834 上罩 Handle upper Cover 1

5 02.01.9048 加速器 Accelerator 1

6 02.FGJ.32835 下罩 Handle Lower Cover 1

7 03.03644 螺钉 M5×50 Screw 2

8 03.01410 螺钉 M5×25 Screw 2

9 02.01.2193 钥匙开关 Key Switch 1

10 02.YYL.2391 手柄盒盖 Handle Key Box 1

11 03.0139 螺钉 M5×10 Screw 2

12 03.01340 螺钉 M5×35 Screw 2

13 03.0312 圆柱销Φ4×16 Cylindrical Pin 2

14 30.01.3270 拉手 Knob 1

15 30.01.3268 连扳 Connecting Board 1

16 03.0703 销轴Φ4×8 Axis Pin 1

17 30.01.3292 拉杆 Pull Rod 1

18 02.01.3161 链条 Chain 1

19 30.01.3272 带孔螺栓 Eye Bolt 1

20 03.0255 螺母 M5 Nut 1

21 03.02441 螺母 M5 Nut 1

22 03.0147 螺钉 M6×16 Screw 2

23 03.0011 弹垫Φ6 Spring Washer 3

24 03.03101 圆柱销Φ4×30 Cylindrical Pin 1

25 81.020.0003 手柄 Handle Bar 1

26 03.0692 带肩复合套 Composite Set With Shoulder

27 30.02.046 转动轴 Rotation Shaft 1

28 03.0303 圆柱销Φ5×35 Cylindrical Pin 2

29 03.01301 螺钉 M3×25 Screw 2

30 03.00091 弹垫Φ3 Spring Washer 2

31 02.01.9274 接近开关 Proximity Switch 1

32 03.0175 螺钉 M6×10 Screw 1

33 03.0049 平垫Φ6 Flat Washer 1

34 03.0601 卡箍 Clamp 1

35 30.01.3293 下压滚子 Pressing Roller 1

36 30.02.047 压轴 Shaft 1

37 03.0702 圆柱销Φ3×22 Cylindrical Pin 1
