Description

1 30.28.0190 Flange 1

2 03.0063 17 Circlip For Shaft 1

3 03.90.0011 3203 Bearing 1

4 03.0027 40 Circlip For Hole 1

5 03.0372 M12×70 Bolt 1

6 30.28.0189 Bracket 1

7 03.0245 M12 Nut 2

8 03.04790 Spring 2

9 01 30.01.6685 Wheel Frame 1 -210125

9 02 40.11.048 Wheel Frame 1 210125-

10 03.90.042 6003 Bearing 2

11 30.01.6614 Shaft Sleeve 1

12 02.01.3368 Balance Wheel 1

13 03.01731 M12×55 Screw 1

14 40.11.082 Wheel Frame Bushing

A 02.QD.0287 Driving Assembly

1 02.01.3703 Oil Seal 油封 1

2 03.0147 Screw M6×16 螺钉 8

3 03.0011 Lock Washer Φ6 弹垫 16

4 02.QDL.0272 Driving Wheel 驱动轮 1

4 02.QDL.3316 Driving Wheel(Rubber) 驱动轮(橡胶) 1 Option

5 02.DJ.00852 Motor 电机 1 For MY

5 70401000004 Motor 电机 1

6 03.0716 Parallel Key 平键销 1

7 02.01.00702 Gear 主动斜齿轮 1

8 03.0062 Circlips For ShaftΦ16 轴用挡圈 1

9 03.0061 Circlips For ShaftΦ15 轴用挡圈 2

10 02.01.006810 Bearing 61824 轴承 2

11 02.01.9294 Spacer 隔套 1

12 03.0709 Circlips For HolesΦ150 孔用挡圈 1

13 02.01.00687 Gear 内齿轮 1

14 02.01.3681 Oil Seal 油封 1

15 02.01.9287 Gear Box 齿轮箱 1

16 03.0012 Lock Washer Φ8 弹垫 5

17 03.0157 Screw M8×30 螺钉 5

18 03.90.074 Bearing 16003 轴承 1

19 02.01.00701 Gear 传动齿轮 1

20 03.0717 Parallel Key 平键销 1

21 02.01.00703 Gear 被动斜齿轮 1

22 03.90.075 Bearing 61905 轴承 1

23 02.01.210707 Gear Box Cap 箱盖 1

24 03.0719 Oil Seal 油封 1

25 03.01049 Screw M6×20 螺钉 8

26 03.0506 Grease Fitting 黄油嘴 1

27 03.04350 Round PinΦ5×20 圆柱销 2

28 03.0975 Parallel Key 平键销 1

29 02.01.3596 Brake Assembly 制动器总成 1

30 02.01.0284 Terminal Box 接线盒 1

31 19.0526 Brush 碳刷 1

31 70431000003 Brush 碳刷 1

16 02.01.2316 Shock Pad 1

17 03.0258 118 Nut 1

18 02.01.9274 ProAimity Switch 1

19 03.00)91 3 Spring Washer –

20 03.01301 113X25 Screw –

21 03.0692 Campsite Set With Shotlder

22 30. Ul. 3293 Pressing Kol ler I

23 30.02.047 Shaft 1

24 03.0702 3X22 Cylindrical Pin 1

1 02_SB.PJ.0004 喇叭按钮 Horn Button

2 02_SB.PJ.0005 上升按钮 RisingButton

3 02_SB.PJ.0009 下降按钮 DeclineButton

4 02_SB.PJ.0010 弹簧7×16 Spring

5 02_SB.PJ.0002 上盖 Upper Cover

6 02_SB.PJ.0006 微动开关卡板 Micro Switch Card

7 02_SB.PJ.0007 微动开关 Micro Switch

8 02_SB.PJ.0012 螺钉ST2.9×9.5 Screw

9 02_SB.PJ.0027 加速器旋钮 Accelerator Knob

10 02_SB.PJ.0025 轴外套 Shaft Jacket

11 02_SB.PJ.0024 轴内套 Shaft Sleeve

12 03.0735 波形弹性垫圈 Spring Washer

13 02_SB.PJ.0008 急反开关 Switch

14 02_SB.PJ.0011 螺钉ST2.2×13 Screw

15 02_SB.PJ.0023 加速器 Accelerator

16 02_SB.PJ.0014 下盖 Lower Cover

17 03.0134 螺钉M5×45 Screw

18 03.05364 螺钉M3×12 Screw

19 02_SB.PJ.0021 螺钉ST2.9×13 Screw

20 02_SB.PJ.0017 钥匙盒 Key Box
