Description

1 03.0149 M6×20 Screw 1

2 03.0257 M6 Nut 1

3 33.050.0001 (550) Frame 1

3 33.050.0002 (685) Frame 1

3 33.050.0003 (550) Frame Low Release 1 Option

3 33.050.0004 (685) Frame Low Release 1 Option

4 30.02.045 Front Seal Plate 1

5 03.0087 M6×10 Screw 4

6 03.0243 M10 Nut 2 Option

7 30.28.0137 Roller 2 Option

7 30.28.0153 Roller(Low Release) 2 Option

8 03.1088 M10×60 Bolt 2 Option

9 82.45.0006 Push Rod Assembly 2

9 82.45.0012 Push Rod Assembly (low Release) 1 Option

10 30.01.6569 Small Axis 2

11 03.0305 5×30 Cylindrical Pin 2

12 03.0024 25 Circle For Hole 2

13 82.451.0001 (550) Ring Rod Assembly 1

13 82.451.0002 (685) Ring Rod Assembly 1

13 82.451.0009 (550 Ring Rod Assembly Low Release 1 Option

13 82.451.0008 (685) Ring Rod Assembly Low Release 1 Option

13 82.451.0011 (550) Ring Rod Assembly 1 Power Unit

13 82.451.0010 (685) Ring Rod Assembly 1 Power Unit

13 82.451.0014 (550) Ring Rod Assembly Low Release 1 Power Unit

13 82.451.0013 (685) Ring Rod Assembly Low Release 1 Power Unit

14 30.01.3311 (550) Back Shaft 1

14 30.28.0089 (685) Back Shaft 1

15 03.05360 M3×16 Screw 2 Power Unit

16 03.00091 3 Spring Washer 2 Power Unit

17 02.01.2178 Micro Switch 1 Power Unit

18 30.20.0052 Mounting Plate 1 Power Unit

19 03.0054 4 Flat Washer 2 Power Unit

20 03.0008 4 Spring Washer 2 Power Unit

21 03.0123 M4×10 Screw 2 Power Unit

8 03.0451 )USVUYOZK9KZ 4

9 03.0303 )_ROTJXOIGR6OT 8

10 30.28.0093 6[YN8UJ9NGLZ 2

11 55103000006 =NKKR(XGIQKZ 2

12 30.01.2845 *XUV5[Z8URRKX 2

13 03.0453 )USVUYOZK9KZ 4

14 30.28.0164 =NKKR(XGIQKZ9NGLZ 2

15 30.01.3629 9NGLZ 2

16 1000320001 (KGXOTM 4

17 02.LZ.0137 6UR_ NKKRY 2

1 03.0691 Composite Set 4

2 33.050.0005 (550) Ring Rod Assembly 1

2 33.050.0006 (685) Ring Rod Assembly 1

2 33.050.0007 (550) Ring Rod Assembly Low Release 1 Option

2 33.050.0008 (685) Ring Rod Assembly Low Release 1 Option

2 33.050.0009 (550) Ring Rod Assembly 1 Power Unit

2 33.050.0010 (685) Ring Rod Assembly 1 Power Unit

2 33.050.0012 (550) Ring Rod Assembly Low Release 1 Power Unit

2 33.050.0013 (685) Ring Rod Assembly Low Release 1 Power Unit

3 03.04422 Composite Set With Shoulder 2

4 30.01.6601 Push Rod Bracket 2

5 03.0286 M22×1.5 Nut 2

6 33.030.0016 Push Rod Welding 2

6 33.030.0025 Push Rod Welding (Low Release) 2 Option

7 03.0451 Composite Set 4

8 03.0303 5×35 Cylindrical Pin 10

9 30.28.0093 Push Rod Shaft 2

10 03.0305 5×30 Cylindrical Pin 2

11 30.28.0164 Wheel Bracket Shaft 2

12 03.0453 Composite Set With Shoulder 4

13 30.01.2845 Drop Out Roller 2 Option

14 30.28.0082 Wheel Bracket 2

15 30.01.1290 Connecting Plate 4

16 03.90.057 6204 Bearing 8

17 02.LZ.0128 Small Roller 4 Not Applicable

17 02.LZ.01261Small Roller(Low Release)ApplicableOption

18 30.28.0094 Bearing Wheel Pin ShaftApplicable

1 82.451.0003 Handle Components 1 Power Unit

1 82.451.0004 Rema Handle Components 1 Power Unit

2 30.20.0014 Rotation Shaft 1

3 03.0303 5×35 Cylindrical Pin 1

4 03.07391 Steel Ball 1

5 02.YG.3690 Oil Cylinder Assembly

6 03.0156 M8×25 Screw 4

7 03.0012 8 Spring Washer 9

8 30.20.0015 Mounting Plate Left

9 03.0149 M6×20 Screw 4

10 03.0011 6 Spring Washer 4

11 30.20.0016 Mounting Plate Right

12 02.01.9354 Check Ring 1

13 03.05131 O O Sharp Ring 1

14 02.DLDY.3475 Power Unit 1

15 03.0226 M5×12 Screw 4

16 02.FGJ.34473 Motor Cover Red 1

16 02.FGJ.34474 Motor Cover Green 1

16 02.FGJ.34476 Motor Cover Yellow 1

16 02.FGJ.0003 Motor Cover Blue 1

17 03.0159 M8×40 Screw 4

18 30.20.0017 Drive Clamping Plate

19 40.16.046 piston Rod

20 30.20.0013 Top Cover 1

21 03.1060 Spring 1

22 03.90.0121 51113 Bearing 1

23 33.048.0001 Balance Frame Left 1

24 30.20.0006 Bearing Bridge 1

25 33.048.0002 Balance Frame Right 1

26 30.01.6569 Small Axis 2

27 03.0306 5×40 Cylindrical Pin 2

28 03.90.091 6013 Bearing 1

29 02.QD.0287 Driving Assembly 1

30 03.0165 M10×25 Screw 6

31 03.0014 10 Spring Washer 6

32 03.0043 10 Flat Washer 6

33 40.16.004 Driving Cover 1

33 40.16.001Driving Cover(With Balance Wheel)1 Option

34 33.048.0021 Balance Frame Left 1 Option

35 33.048.0022 Balance Frame Right 1 Option

36 01 81.005.002Balance Wheel Assembly 2 -210125 Option36 02 81.005.023Balance Wheel

Assembly 2 210125- Option

37 03.0049 6 Flat Washer 8 Option

38 03.0011 6 Spring Washer 8 Option

39 03.0147 M6×16 Screw 8 Option
