Description

31401001 * Handle tube assy.(Incl.1, 4, 10~12)

31101078 * Control box assy. (Intelligent control) (Yellow color control knob)

31101196 / Control box assy. (Intelligent control) (Red color control knob)

31101079 * Handle assy. (Intelligent control) option (Inc. Item 1~2, 7~8)

31101197 / Handle assy.(Inc. Item 1~2, 7~8) (Intelligent control)

21402003 * Self-Lubricating Bearing 20*30*16.5

20901001 * Spring Pin Ø5*35

31102127 * Handle shaft Ø20*100 (2021.04.10~)

10302018 * Handle cables

31102124 * Plastic cable clamp

31102038 * Pressure Roller with bearing

31102039 * Roller Axle

20901010 * Sping pin 4*20

30202004 * Emergency reverse button

30202005 * Spring

10301010 * Inching switch

30202002 * Bottom cover

20101402 * Screw M4*16

20101401 * Screw

10301012 * Potentiometer

30202008 * Inner Column spacer

30202007 * Outer Column spacer

30202009 * Control Knob (Yellow color) (~2023.2.19)

30202057 Control Knob (Red color)(2023.2.20~)

20302008 * Screw M3*12 (2020.11.01~)

20301004 * Screw M3*16

10301061 * Monitor (Intelligent control) option

30202003 * Front cover

30202006 * Sticky board

31101012 * Potentiometer assy.(Inc. Item 7~11) (Yellow color control knob)

31101134 Potentiometer assy.(Inc. Item 7~11) (Red color control knob)

31101081 * Handle upper cover assy. (Intelligent control) option

20101405 * Screw M4*12

10302055 * Cable harness for control box assy.

31102127 * Handle shaft Ø20*100 (2021.04.10~)

20901001 * Spring Pin Ø5*35

31101119 * Handle socket assy.(2021.04.10~)

20101802 * Screw M8*25

20601001 * Washer Ø8

20503001 * Bearing 51113

31502004 * Continuous frame(2021.08.15~)

20501002 * Bearing 6013-2RS

10301043 * Buzzer

20102402 * Screw M4*8

31102002 * Wires cover for EPT15H

31502003 * Wires cover for EPT20H

20101505 * Screw M5*16

31102004 * Mounting plate for controller

20103602 * Screw M6*16

10301062 * Controller (Intelligent control) option

20101502 * Screw M5*25

31102021 * Wires cover for controller

31102001 * Controller cover

20304502 * Screw M5*16

31101138 * Driving unit assy. (0.75Kw Motor) for EPT15H

31501022 * Driving unit assy. (1.0Kw Motor) for EPT20H

31502005 * Cover standard 30mm ground clearance(2020.05.01~) Option

31502006 * Cover 60mm ground clearance (Standard)

20202601 * Screw M6*12 (2020.11.5~) updated

30102007 * Coupling shaft

20901002 * Spring Pin Ø5*40

20202401 * Screw M4*8

31102054 * Nylon gasket 3mm

31102055 * Nylon gasket 2mm
