2409001203001 flange gasket-Fuel injection pump FOR quanchai engine QC490
| Product name | flange gasket-Fuel injection pump |
| Parts number | 2409001203001 |
| Used for | quanchai engine QC490 |
Description
| 2409000100000 – Engine Block Assembly |
| 2409000110001 – Engine Block Machined Assembly |
| 2409000110101 – Engine Block |
| 2409000110200 – Camshaft Rear Bushing |
| 2409000110300 – Bowl Plug |
| 2409000110400 – Rear Main Bearing Cap |
| 2409000110500 – Camshaft Middle Bushing |
| 2409000110600 – Camshaft Front Bushing |
| 2409000110800 – Main Bearing Cap |
| 2409000110900 – Main Bearing Cap Bolt |
| 2409000111100 – Main Oil Passage Plug |
| 2409000110700 – Branch Oil Passage Plug |
| 1408500311000 – Plug |
| 1408500310200 – Bowl Plug |
| 2409000100201 – Cylinder Liner |
| 2409000100300 – Cylinder Head Bolt (Type A) |
| 2409000100401 – Cylinder Head Bolt (Type B) |
| 2409000100503 – Cylinder Head Gasket |
| 2409000100700 – Cylinder Liner Water Seal Ring |
| 2409000101213 – Inlet Pipe |
| 2409000101304 – Inlet Pipe Gasket |
| 2409000101400 – Drain Valve Connector |
| 2409000103700 – Drain Valve Assembly |
| 2409000103802 – Drain Valve Hose |
| 2409000101800 – Rear Oil Seal Cover |
| 2409000101900 – Rear Oil Seal Cover Gasket |
| 2409000102100 – Crankshaft Thrust Washer (Lower) |
| 2409000102200 – Crankshaft Thrust Washer (Upper) |
| 2409000102500 – Main Bearing Shell (Lower) |
| 2409000102600 – Main Bearing Shell (Upper) |
| 1 1408500301700 – Oil Filter Gasket |
| 2. GB/T9877.1-1988 – Oil Seal FB100×130×12 |
| 3. 1408500300403 – Oil Pressure Alarm |
| 4. 1408500311300 – Vacuum Pump Oil Inlet Plug M10×1 |
| 5. 1408500311400 – Vacuum Pump Oil Return Plug M16×1.5 |
| 6. GB/T5783-2000 – Bolt M8×30 |
| 7. GB/T93-1987 – Washer M8 |
| 8. GB/T97.1-2002 – Washer M8 |
| 9. GB/T5783-2001 – Bolt M8×25 |
| 10. GB/T93-1987 – Washer M8 |
| 11. GB/T97.1-2002 – Washer M8 |
| 12. GB/T119.1-2000 – Pin B8×20 |
| 13. GB/T119.1-2000 – Pin B10×22 |
| 14. GB/T119.1-2000 – Pin B16×16 |
| 15. GB/T91-2000 – Cotter Pin 2.5×20 |
| 16. 2409000103323 – Front Bracket (Right) |
| 17. 2409000103223 – Front Bracket (Left) |
| 18. GB/T5783-2000 – Bolt M10×25 |
| 19. GB/T93-1987 – Washer M10 |
| 20. GB/T97.1-2002 – Washer M10 |
| 21. 2409000700907 – Transport Front Bracket |
| 22. GB/T5783-2000 – Bolt M16×40 |
| 23. GB/T93-1987 – Washer M16 |
| 24. GB/T6170-1988 – Nut M16 |
| 25. 2409004400100 – Water Inlet Dust Cover |
| 26. 2409000200001 – Timing Gear Train Assembly |
| 27. 2409000200301 – Fuel Injection Pump Timing Gear |
| 28. 2409000200401 – Timing Idler Gear Shaft |
| 29. 2409000210001 – Timing Idler Gear Component |
| 30. 2409000210100 – Timing Idler Gear Bushing |
| 31. 2409000210201 – Timing Idler Gear |
| 32. 2409000200701 – Crankshaft Timing Gear |
| 33. 2409000200800 – Camshaft Thrust Plate |
| 34. 2409000200901 – Camshaft Timing Gear |
| 35. 2409000201201 – Idler Gear Shaft Pressure Plate |
| 36. 2409000201411 – Fuel Injection Pump Timing Gear Coupling Disk |
| 37. 2409000201500 – Countershaft Gear |
| 38. 2409000201607 – Hydraulic Pump Gear |
| 39. 2409000201700 – Countershaft Gear Shaft Pressure Plate |
| 40. 2409000201800 – Countershaft Gear Shaft |
| 41. 2410200500600 – Camshaft Timing Gear Pressure Plate |
| 42. GB/T297-1994 – Bearing 30207 |
| 43. GB/T276-1994 – Rolling Bearing 6009 |
| 44. GB/T893.1 – Retaining Ring 75 |
| 45. 2409003200000 – Gear Cooling Nozzle Assembly |
| 46. 2409003210000 – Gear Cooling Nozzle Component |
| 47. 2409003200100 – Bushing Sleeve |
| 48. GB/T5782 – Bolt M8×60 |
| 49. GB/T5783 – Bolt M8×16 |
| 50. GB/T93-1987 – Washer 8 |
| 51. GB/T70.1 – Screw M8×50 |
| 52. GB/T93-1987 – Washer 8 |
| 53. GB/T5783 – Bolt M12×30 |
| 54. GB/T93-1987 – Washer 12 |
| 55. GB/T5783 – Bolt M6×16 |
| 56. GB/T93-1987 – Washer 6 |
| 57. 2409000300007 – Cylinder Head Assembly |
| 58. 2409000300100 – Rocker Arm Shaft Support Bolt |
| 59. 2409000300202 – Intake Manifold Gasket |
| 60. 2409000300303 – Exhaust Manifold Gasket |
| 61. 2409000300400 – Valve Outer Spring |
| 62. 2409000300500 – Valve Inner Spring |
| 63. 2409000300600 – Valve Collet |
| 64. 2409000300700 – Valve Spring Retainer |
| 65. 2409000300912 – Lifting Lug |
| 66. 2409000300900 – Lifting Lug |
| 67. 2409000301200 – Rear End Cover |
| 68. 2409000301304 – Rear End Cover Gasket |
| 69. 2409000301404 – Intake Valve |
| 70. 2409000301502 – Exhaust Valve |
| 71. 2409000301701 – Fuel Injector Pressure Plate |
| 72. 2409000301800 – Fuel Injector Pressure Plate Bolt |
| 73. 1408500201100 – Valve Oil Seal Assembly |
| 74. 2409000310007 – Cylinder Head Machined Component |
| 75. 2409000310105 – Cylinder Head |
| 76. 2409000310200 – Valve Guide |
| 77. 2409000310700 – Intake Valve Seat |
| 78. 2409000310800 – Exhaust Valve Seat |
| 79. 1408500310200 – Bowl Plug |
| 80. 1408500210200 – Bowl Plug |
| 81. 2409530310600 – Plug Sleeve |
| 82. 2409000320000 – Valve Rocker Arm Shaft Component |
| 83. 2409000320100 – Gasket |
| 84. 2409000320200 – Front Rocker Arm Seat |
| 85. 2409000320301 – Valve Lash Adjusting Screw |
| 86. 2409000320400 – Rocker Arm Seat |
| 87. 2409000320500 – Valve Rocker Arm Spring |
| 88. 2409000320601 – Rocker Arm Shaft |
| 89. 1408500220300 – Valve Lash Adjusting Nut |
| 90. GB/T73-1985 – Screw M10×1×10 |
| 91. GB/T894.1-1986 – Retaining Ring 18 |
| 92. 2409000321000 – Valve Rocker Arm Assembly |
| 93. 2409000321100 – Valve Rocker Arm |
| 94. 2409000321200 – Valve Rocker Arm Bushing |
| 95. 3408525100502 – Glow Plug |
| 96. 3409020201001 – Glow Plug Connecting Wire (Black) |
| 97. GB/T5783-2000 – Bolt M8×20 |
| 98. GB/T93-1987 – Washer 8 |
| 99. GB/T5783-2000 – Bolt M8×20 |
| 100. GB/T93-1987 – Washer 8 |
| 101. 2409000400000 – Piston and Connecting Rod Assembly |
| 102. 2409000400112 – Piston |
| 103. 2409000430001 – Piston Ring Component |
| 104. 2409000430101 – First Compression Ring |
| 105. 2409000430201 – Second Compression Ring |
| 106. 2409000400400 – Piston Pin |
| 107. GB/T983.1 – Retaining Ring 29 |
| 108. 2409000431001 – Oil Ring Component |
| 109. 2409000431101 – Ring Body |
| 110. 1409000511302 – Latch Pin |
| 111. 1409000511202 – Helical Support Spring |
| 112. 2409000420000 – Connecting Rod Component |
| 113. 2409000420100 – Connecting Rod Bushing |
| 114. 2409000420200 – Connecting Rod Body |
| 115. 2409000420300 – Connecting Rod Bearing Shell |
| 116. 2409000420400 – Connecting Rod Cap |
| 117. 2409000420500 – Connecting Rod Bolt |
| 118. 2409000500033 – Crankshaft and Flywheel Assembly |
| 119. 2409000500200 – Flywheel Bolt |
| 120. 2409000500401 – Crankshaft |
| 121. 2409000500608 – Crankshaft Pulley |
| 122. 1408500600200 – Pulley Compression Gasket |
| 123. 2409000510033 – Flywheel Ring Gear Component |
| 124. 2409000510133 – Flywheel |
| 125. 2409000510300 – Ring Gear |
| 126. 1408500600300 – Pulley Compression Bolt |
| 127. 2409000500800 – Flywheel Bearing Bushing |
| 128. GB/T276-1994 – Bearing 6302-2RS |
| 129. GB/T1096-2003 – Key A12×63 |
| 130. GB/T119.1-2000 – Pin φ10×22 |
| 131. GB/T119.1-2000 – Pin φ6×16 |
| 132. 2409000600000 – Camshaft Assembly |
| 133. 2409000600102 – Camshaft |
| 134. 2409000600200 – Valve Tappet |
| 135. 2409000600300 – Valve Push Rod |
| 136. GB/T1096-2003 – Key C8×22 |
| 137. 2409000700006 – Oil Pan Assembly |
| 138. 2409000700104 – Oil Pan Gasket |
| 139. 2409000710006 – Oil Pan Weldment |
| 140. 2409000710103 – Oil Pan Body |
| 141. 2409000722007 – Oil Dipstick Assembly |
| 142. 1408501110400 – Oil Drain Plug Seat |
| 143. 1408501100301 – Oil Drain Plug |
| 144. JB/T982-77 – Seal Ring |
| 145. GB/T5783-2000 – Bolt M8×20 |
| 146. GB/T93-1987 – Washer M8 |
| 147. 2409000800000 – Exhaust Manifold Assembly |
| 148. 2409000800116 – Exhaust Manifold |
| 149. 2409000800204 – Exhaust Manifold Gasket |
| 150. GB/T5783-2000 – Bolt M10×30 |
| 151. GB/T93-1987 – Washer M10 |
| 152. GB/T898-1998 – Stud Bolt M10×25 |
| 153. GB/T6170-2000 – Nut M10 |
| 154. GB/T93-1987 – Washer 10 |
| 155. GB/T97.1-2002 – Washer M10 |
| 156. 2409004400402 – Exhaust Port Dust Cover |
| 157. 2409000900000 – Intake Manifold Assembly |
| 158. 2409000900107 – Intake Manifold |
| 159. 2409000900323 – Intake Manifold Adapter |
| 160. 2409533710108 – Wire Harness Bracket |
| 161. 1408500900300 – Intake Adapter Gasket |
| 162. GB/T5782-2000 – Bolt M8×20 |
| 163. GB/T93-1987 – Washer M8 |
| 164. GB/T97.1-2002 – Washer M8 |
| 165. GB/T5782-2000 – Bolt M8×30 |
| 166. GB/T93-1987 – Washer M8 |
| 167. GB/T97.1-2002 – Washer M8 |
| 168. 2409004400303 – Intake Port Dust Cover |
